Overview

Features

  • 30A AC RMS (10mV/A output sensitivity)
    • ±1% of reading ±50mA accuracy
    • ±50mA resolution
  • 300A AC RMS (1mV/A output sensitivity)
    • ±1% of reading ±300mA accuracy
    • ±100mA resolution
  • ±45A and 450A DC
  • 600A AC RMS max inrush current
  • 20kHz frequency
  • 19mm maximum conductor diameter

This product is an accessory for the following products:

Description

The Fluke i310s AC/DC current clamp is based on Hall-effect technology. This battery-powered clamp measures both ac and dc current. It may be used with ScopeMeter and other suitable recording instruments for accurate non-instrusive current measurement. This clamp is especially useful for current measurements on inverters, switching power supplies, industrial controllers, automative diagnostics, and other applications requiring current measurements and/or waveform analysis.
