Dwyer MTL7706 Zener Barrier

MTL7706 (Dwyer)

Dwyer Instruments

Not in stock. Usually ships in 4-6 business days [?]

Need Help? Call a Temperature Engineer 1-800-884-4967

We're open Mo-Th 8am to 5:30pm. Fr 8am to 5pm ET


  • Transmitter Voltage: 16.2 V @ 20 mA with 250Ω load (negative w.r.t. earth); 11.0 V @ 20 mA with 500Ω load (negative w.r.t. earth)
  • Safe Area Output: 4 to 20 mA
  • Load Resistance: 0 to 500Ω.
  • Accuracy: ±2 µA under all conditions
  • LED Indicator
  • Safety Description: 28 µV, 300Ω, 93 mA

This product is an accessory for the following products:

Dwyer IS626 Pressure Transmitter
Intrinsically safe pressure transmitter, ranges up to 500 psig 0.25% accuracy
Dwyer ISDP Pressure Transmitter
Intrinsically safe differential pressure transmitter for hazardous zone pressure and flow applications
Mercoid PBLT2 Level Transmitter
Lightning protected submersible transmitter is ideal for level measurements of sludge and slurries
Mercoid SBLT2 and SBLTX Level Transmitters
Submersible level transmitters with proven piezoresistive sensing technology and optional hazardous area approvals

The Dwyer MTL7706/7787 is an intrinsically safe (IS) shunt-diode barrier that can be used to communicate with and provide isolations for certain Dwyer transmitters approved for use in hazardous areas. These barriers limit the amount of energy allowed to pass into the hazardous area, which inhibit ignition in flammable atmospheres.
