Additel ADT 783 Pressure Controller
Three selectable base units with pressure ranges from -14.35 to 3,600 psi.
Overview
Features
- Max. pressure range:
- ADT783-D: 35 psi
- ADT783-1K: 1,000 psi
- ADT783-3.6K: 3,600 psi
- Min. pressure range: -14.35 psi for all units
- Precision:
- ADT783-D:
- 0.015% FS (DP2 to DP5)
- 0.025% FS (DP10 to DP1K)
- ADT783-1K:
- 0.01%FS, 0.007% FS, or 0.008% RD
- ADT783-3.6K:
- 0.01% FS, 0.007% FS, or 0.007% RD
- ADT783-D:
- Accuracy:
- ADT783-D:
- 0.015% FS (DP2 to DP5)
- 0.025% FS (DP 10 to DP1K)
- ADT783-1K:
- 0.01% FS, 0.007% FS, or 0.008% RD
- ADT783-3.6K:
- 0.02% FS, 0.01% FS, or 0.01% RD
- ADT783-D:
- <0.003% FS control stability, typically 0.001% FS
- <10s control response time
- Optional barometric pressure module
What's in the Box
- (1) ADT 783 Pressure controller
- (1) AC power cord (10A 250V)
- (1) ISO17025 accredited calibration certificate
- (2) Green terminal plug for switch detection
- (10) O-ring 3.5*1.5 for ADT151
- (2) Festo plug 6mm for sealing (only for ADT783-D)
- (3) 0.3m silicone tube, 120 kPa max (only for ADT783-D)
- (2) 1.5m polyurethane tube, 700 kPa max (only for ADT783-D)
- (2) ADT100-BARB-FESTO (only for ADT783-D)
- (2) 1.5m standard vent assembly, plug with vent valve (only for ADT783-1K/3.6K)
Description
The Additel ADT 783 Pressure Controller is ideal for users requiring automated production, testing, and calibration. The ADT 783 can quickly be outfitted with two controlling ADT151 modules and one reference barometric module to cover a wide pressure range. For all selectable base units, select between one or two ADT151 pressure control modules. An optional barometric module can be added that allows for gauge and absolute measurements. Each module comes with a dual-range calibration, expanding measurement accuracy within each module.
The ADT783-1K is designed for gauge pressure calibration from -14.35 up to 1,000 psi. At least one ADT151 pressure module within the range of CP50 to CP1K must be installed in the high side module bay.
The ADT783-3.6K is designed for gauge pressure calibration from -14.35 up to 3,600 psi. At least one ADT151 pressure module within the range of CP2K to CP3.6K must be installed in the high side module bay.
The ADT783-D is designed for differential and gauge pressure calibration to as low as ±10 inH2O up to 36 psi. At least one ADT151 pressure module within the range of DP30 to DP1K must be installed in the high side module bay.
On all models, the low module bay can be left empty, but when a low-pressure module is installed, the range must be lower than the installed high-pressure module.
