Intempco LTX05 Capacitance Level Sensor

Name: Intempco LTX05 Capacitance Level Sensor
Price: 616.0 USD
Availability: BackOrder

OEM capacitance level transmitter for water-based liquids.

Starting at $616.00

View Company Reviews

Manufactured

By Intempco

Includes

FREE Ground Shipping on orders of $1,000 or more
FREE Lifetime Tech Support

Availability

Usually ships in 2-3 weeks

Product Manual Product Specs

Features

Teflon-jacketed solid SS probe
Standard or custom probe lengths from 6 inches to 11 feet
392°F (200°C) max process temp
Pressure limits vary based on model and temp
- 100 psi (7 bar) @ 77°F (25°C); P model only
- 500 psi (34 bar) @ 77°F (25°C); PH model only
- 250 psi (17 bar) @ 302°F (150°C)
- 14.5 psi (1 bar) @ 392°F (200°C)
NEMA 4 rated aluminum housing
Standard fitting 3/4 NPT
Continuous loop powered 4-20 mA operation
Microprocessor Based
Non-interacting zero and span
Calibration accomplished with 4 push buttons
12 to 36 VDC supply power

The LTX05 level sensors are primarily designed for OEM continous liquid level measurement applications. The assembly consists of NEMA 4 aluminum flip-cover head which houses the electronics, stainless steel process connection and PFA teflon® coated stainless steel probe. LTX05 can withstand extremely corrosive materials. The rugged construction is gas-tight to pressures from vacuum to 34 bar (500 psi). LTX05 is low cost and intended for OEM applications.

LTX05 series, 2 wire level transmitters, are highly reliable microprocessor based, sensors designed to measure tank levels of liquids or certain dry bulk media. LTX sensors measure the change in capacitance that occurs as the tank level changes, and outputs a standard loop-powered 4-20 mA signal. LTX sensors use very high frequency, very low amplitude sensing circuitry to greatly minimize the effects of coating on the sensing probe. Calibration, zero and span, is accomplished via 4 push-buttons on the transmitter.
