Micro Motion CDM100 Compact Density Meter

Designed for metering of high-value products such as crude oil, refined hydrocarbons, alcohol, & many aggressive process liquids.

Starting at $13,523.00

View Company Reviews
Manufactured
Includes
Availability
  • Usually ships in 8-10 weeks
Product Manual Product Specs

Features

  • 0 to 3000 kg/m3 (0 to 3 g/cm3) operating density
    • 0 to 1000 kg/m3 (0 to 1 g/cm3) for TPS versions
  • Up to ±0.1 kg/m3 (±0.0001 g/cm3) accuracy
  • ±0.02 kg/m3 (±0.00002 g/cm3) repeatability
  • 300 to 1300 kg/m3 (0.3 to 1.3 g/cm3) calibration range
  • -58 to 400°F (-50 to 204°C) operating temp range
  • 100Ω RTD integral temperature sensor
  • 389 psig (27 bar) max working case pressure
    • Typical burst pressure is 2824 psig (195 bar)

The Micro Motion CDM100 compact density meter uses dual curved-tube meter technology to measure density and Coriolis to indicate (velocity/volume) flow rate. It is available in general purpose stainless steel and peak performance nickel alloy manifold versions.

General Purpose Manifold (CDM100M)

  • 316L stainless steel material
  • ±0.2 kg/m3 (±0.0002 g/cm3) liquid accuracy
  • 1450 psi (100 bar) or flange limit max working pressure of sensor

Peak Performance Manifold (CDM100P)

  • Nickel Alloy C22 material
  • ±0.1 kg/m3 (±0.0001 g/cm3) liquid accuracy
  • 3600 psi (248 bar) or flange limit max working pressure of sensor
