Tek Know Hydraulic Hand Held Pressure Calibrator
Hydraulic pressure calibrator up to 10,000 psi.
Overview
Features
- True calibration: Provides true pressure references, not simulated ones
- Accurate measurement: Accurate to 0.05% full scale, including hysteresis, repeatability, and temperature effect
- Operating temperature range: From -10°C (14°F) to 50°C (112°F)
- Rugged and compact design: Weighing only 6.6 lbs, it's the optimal choice for field use
- Communications port: RS232 interface is standard, with optional Windows-based calibration software
- Indicator or hand pumps can be ordered separately
Description
The PM110 Series includes unique hand-held digital pressure calibration systems with accuracies of 0.05% or 0.1% full scale, including hysteresis, repeatability, and temperature effect. The PM110 Series is ideal for on-site calibration of pressure transducers, pressure transmitters, pressure switches, pressure relief valves, or any other digital or analog pressure instrumentation.
The standard RS232 interface can be linked with our PRE-CAL software for efficient document control and calibration certificates traceable to national and international standards.
The standard RS232 interface can be linked with our PRE-CAL software for efficient document control and calibration certificates traceable to national and international standards.
Accessories
