Dynasonics TFX-500w Ultrasonic Flow Meter
Starting at $1,775.00

Some models in stock. View available part numbers.

Need Help? Call a Flow Engineer 1-800-884-4967

We're open Mo-Th 8am to 5:30pm. Fr 8am to 5pm ET

Features

  • Measures clean liquids and those with small amounts of suspended solids or aeration
  • Bi-directional flow measurement system
  • Totalizer with remote reset
  • Modbus RTU or BACnet MS/TP over RS485 and
  • BEACON®/AquaCUE® connectivity
  • NEMA 4X, IP66 polycarbonate enclosure
  • Clamp-on sensor design for reduced installation time
  • No moving parts reduces maintenance
  • 0-20 and 4-20mA analog outputs
  • USB, type mini-B configuration port
  • Large, easy-to-read digital display (optional)
  • Certified for hazardous area installation in North America and Europe (optional)

The Dynasonics TFX-500w ultrasonic flow meter measures volumetric flow of clean water in pipes 10 in. or smaller. This versatile and accurate meter clamps on to the outside of pipes and does not contact the internal liquid which reduces installation and maintenance time and cost. The TFX-500w is available in a variety of configurations that permit the user to select a meter with features suitable to meet particular application requirements. These features make the Dynasonics TFX-500w ideal for building automation, water distribution and wastewater collection in new and retrofit applications.

The TFX-500w has a wide, bi-directional measuring range that ensures reliable readings even at very low and high flow rates. For pipe/tubing sizes of 2" and lower, the TFX-500w includes clamp-on transducers mounted and wired directly to the flow meter electronics enclosure. This design provides a convenient installation in areas where the user requires local indication. The TFX-500w is also available with remote mounted transducers that permit separation of up to 300 feet. This design is utilized when pipes are located in areas that are not convenient for viewing, or on piping systems with severe vibration. This Dynasonics flow meter features a NEMA 4X, IP66 polycarbonate enclosure, optional easy-to-read digital display, bi-directional flow measurement, and a totalizer featuring forward, reverse and net total, and Modbus communications.

Dynasonics RC820648 Connection Cable
10-foot (3.05m) USB A / Mini-B cable for use with TFX-500w ultrasonic flow meter
$15.00
Dynasonics SoloCUE Setup Software
Available on DVD or USB flash drive & compatible with TFX-500w ultrasonic clamp-on flow meters
$42.00

Application Notes

Here's how some of our customers used this product.

Boiler / Chilled Water Flow Measurements

The Background: Our customer is an entertainment park that’s wants a way to monitor the flow of both heated and chilled water throughout the park so they can look for ways increase efficiency and lower costs.

The Problem: The customer is looking for an non-intrusive and economical way to monitor flow. The don’t want to spend a lot of money installing multiple permanent meters.

The Solution: We recommended a Dynasonics TFX-500w ultrasonic flow meter. This clamp-on style meter can be easily moved from location to location and is compatible with the range of water temperatures expected at the park. This is a simple and economical solution to the customer’s needs.

Part Number Price Available
DW-G-KZ-F-S-AC-WW-XX-G-F
Show Configuration
Base Price
$1,775.00
Pipe Size
Adjustable (2 to 10in pipes) (+$190.00)
Transducer Type
DTTK for 6 to 10in pipes (up to 250°F) (+$480.00)
Transmitter Type
24 VDC Remote Mounted
Display
Standard display with keypad (+$150.00)
Remote Cable Length
15ft
Conduit Length
None
Units of Measure Totalizer/Flow Rate
Gallons / Gallons per minute
Tagging
Without
Reconfigure
$2,595.00 1
DW-G-RZ-F-S-AK-WW-XX-G-F
Show Configuration
Base Price
$1,775.00
Pipe Size
Adjustable (2 to 10in pipes) (+$190.00)
Transducer Type
DTTR for 2 to 10in pipes (up to 250°F)
Transmitter Type
24 VDC Remote Mounted
Display
Standard display with keypad (+$150.00)
Remote Cable Length
50ft (+$140.00)
Conduit Length
None
Units of Measure Totalizer/Flow Rate
Gallons / Gallons per minute
Tagging
Without
Reconfigure
$2,255.00 1

Interested in Other Part Numbers?

Other part numbers are available to order but are not currently in stock. Current availability for non-stock parts is "Usually ships in 1-2 weeks". Click here to select options
