Autonics SPB Power Supply
DIN rail mount switching mode power supply with high conversion efficiency.
- By Autonics
-
Some models in stock. View available part numbers.
Overview
Features
- Supports both DIN rail and screw mount installation
- Over-current & output short-circuit protection
- SPB-120 also includes over-voltage protection circuit
- Built-in power factor correction circuit on 120 or 240W
- Low voltage indicator (LED)
- Slim, compact size
- Minimal noise and ripple
- Terminal protection cover for user safety
- Minimal heat generation
- 15, 30, 60, 120, or 240W output power
- 5, 12, 24, or 48VDC output voltage
Description
The Autonics SPB Series switching mode power supplies feature high power conversion efficiency with low noise and ripple and minimal heat generation. The switching mode power supplies can be easily clipped onto DIN rails or mounted on panels using bolts. The series also includes safety features including terminal protection cover, overcurrent protection, output short-circuit protection and overheating prevention.
Documents
In Stock
Part Number | Price | Available | |
---|---|---|---|
SPB-030-24 |
$57.00 | 6 in stock | |
SPB-015-24 |
$49.00 | 5 in stock | |
SPB-060-24 |
$67.00 | 1 in stock | |
SPB-120-24 |
$108.00 | 1 in stock |
Interested in Other Part Numbers?
Other part numbers are available to order but are not currently in stock. Current availability for non-stock parts is "Usually ships in 4-6 business days". Click here to select options
