VEGA VEGABAR 81 Pressure Transmitter

Reliable measurement of highly corrosive and hot media; includes chemical seal.

Call 1-800-884-4967 for pricing
Effective October 1st, 2025 VEGA has added a 9% surcharge for all of their products. The surcharge will appear as a separate line item on the order.

View Company Reviews
Part Number
  • VEGABAR 81
Manufactured
Includes
Availability
  • Usually ships in 1-2 weeks
Product Manual Product Specs

Features

  • -14 to 14,503.8 psi measuring range and process pressure
  • -130 to 752°F process temperature
  • -40 to 176°F ambient temperature
  • 0.2 to 0.1% accuracy
  • Materials, wetted parts:
    • Alloy C22 (2.4602)
    • Alloy 400 (2.4360)
    • Tantalum
    • Alloy C276 (2.4819)
    • Duplex (1.4462)
    • Titanium Grade 2 (3.7035)
    • 1.4435
    • 316/316L
    • Titanium Grade 7 (3.7235)
  • ≥ G½, ≥ ½ NPT threaded connection
  • ≥ DN25, ≥ 1in flange connection
  • No media contact seal material
  • Hygienic fittings:
    • Clamp ≥ 1in - DIN32676, ISO2852
    • Slotted nut ≥ 1½in, ≥ DN40 - DIN 11851
    • Hygienic fitting with tension flange DN32
    • Hygienic fitting F40 with compression nut
    • Hygienic flange connection ≥ DN50 DIN11864-2
    • Hygienic fittings ≥ DN40 - DIN11864-1-A
  • Housing material:
    • Plastic
    • Aluminum
    • Stainless steel (precision casting)
    • Stainless steel (electropolished)
  • Output:
    • Profibus PA
    • Foundation Fieldbus
    • 4 to 20mA
    • Two-wire: 4 to 20mA / HART
    • Modbus
    • Secondary electronics for electronic differential pressure
  • Protection rating:
    • IP66/IP68 (0.2bar)
    • IP66/IP67
    • IP66/IP68 (1bar)
    • IP66/IP68 (25bar)
    • IP69

The VEGA VEGABAR 81 Pressure Transmitter is designed for pressure and level measurement, and includes chemical seals adapted to the process to ensure a reliable measurement even in highly corrosive and hot products.

The pressure measuring cell transforms the pressure into an electrical signal. This pressure-dependent signal is converted by the integrated electronics into a standardized output signal.

The VEGABAR 81 is provided with a completely welded chemical seal system with internal transmission liquid. For measuring ranges up to 40bar, a piezoresistive sensor element is used, from 100bar a strain gauge sensor element.
