ACI VOC Volatile Organic Compound

VOC sensor with a 0 to 1000ppb sensing range, less than 5 second response time, and analog plus Modbus RTU outputs for indoor air quality applications.

Starting at $683.00

View Company Reviews
Manufactured
Includes
Availability
  • Usually ships in 7-10 business days
Product Manual Product Specs

Features

  • Measurement range: 0 to 1000ppb TVOC (isobutene)
  • Sensor type: Metal oxide semiconductor
  • Outputs: 4 to 20mA, 0 to 10VDC, and Modbus RTU via EIA RS-485
  • Mounting options: Room, duct, and probe configurations
  • Response time: Less than 5 seconds
  • Supply voltage: 16 to 28VAC or 16 to 35VDC with reverse polarity protection
  • Operating temperature: 32 to 122°F
  • Operating humidity: 10 to 95% RH, non-condensing
  • Display option: LCD display available with relay output (VOC-R-LCD model)
  • Application: Indoor air quality (IAQ) VOC measurement and monitoring

The ACI VOC Volatile Organic Compound sensor measures from 0 to 1000ppb using a metal oxide semiconductor sensor. The sensor provides 4 to 20mA, 0 to 10VDC, and Modbus RTU communication outputs for integration with building automation systems and indoor air quality monitoring applications. The VOC Series is available in room, duct, and probe mount configurations. Models are offered with an optional LCD display and relay output. The sensor operates on 16 to 28VAC or 16 to 35VDC power and features a response time of less than 5 seconds.

ACI VOC Volatile Organic Compound Applications:

  • Indoor air quality (IAQ) VOC measurement
