Core Sensors CS84 Intrinsically Safe Differential Pressure Transducer

Wet/wet high-strength sensor with differential pressures up to 1,000 psi for measurement in applications such as filtration and external tank levels.

Starting at $840.00

View Company Reviews
Manufactured
Includes
Availability
  • Usually ships in 3-5 weeks
Product Manual Product Specs

Features

  • Differential pressures from 0.5 up to 1,000 psi
  • Bi-directional ranges available
  • 1,000 psi max line pressure
  • Accuracy:
    • ≤ ±0.25% BFSL
    • ≤ ±0.5% BFSL (2 psi and below)
  • ≤ ±0.25% of full scale stability
  • 4 million pressure cycles
  • 2x or 2,000 psi (whichever is less) overpressure
  • 3x configured differential pressure burst pressure
  • Operating temperature:
    • -40 to 176°F (-40 to 80°C)
    • -4 to 176°F (-20 to 80°C) (electrical connection option F)
  • Media temperature:
    • -40 to 257°F (-40 to 125°C)
    • -40 to 221°F (-40 to 105°C) (electrical connection option F)
  • 5 to 149°F (-15 to 65°C) compensated temperature
  • TC Zero:
    • ≤ ±1% of full scale
    • ≤ ±2% of full scale (2 psi and below)
  • TC Span:
    • ≤ ±1% of full scale
    • ≤ ±2% of full scale (2 PSI and below)
  • EMI/RFI protection
  • IP65 rating
  • CSA Class I, Division 1 Groups C,D T4
  • Class I, Zone 0 AEx ia IIB T4 Ga (Ex ia IIB T4 Ga)

The Core Sensors CS84 intrinsically safe differential pressure transducer is designed for measuring differential pressure of liquids and gases in Class I, Division 1 intrinsically safe environments. It uses an all-welded stainless steel construction with a minimum IP65 rating and a 316L stainless steel, oil-filled sensing element that supports stable performance across a range of temperatures and resists corrosion. The device supports differential pressure ranges from 0.5 to 1,000 PSID, with options for uni-directional and bi-directional measurement, and is available with 1/4″ MNPT or FNPT process connections.

The CS84 transducer has a fully welded design without internal O-rings or seals, allowing operation in wet/wet, wet/dry, or dry/dry conditions. It is used in applications such as filter monitoring, sealed tank level measurement, and flow measurement across an orifice, and can be configured for use in demanding operating conditions.

Core Sensors CS84 Intrinsically Safe Differential Pressure Transducer Applications

  • Filtration
  • External tank level measurement
  • Compression systems
