Define Instruments PRO-RTD Panel Meter
Starting at
$412.00

Need Help? Call 1-800-884-4967
Mo-Th 8am to 5:30pm. Fr 8am to 5pm ET

Features

  • Accepts input from up to four RTD sensors
    • Supplies 160µA excitation
    • 0.1°C resolution
    • ±30ppm/°C FS max span drift
    • 5Hz processing rate
    • Choice of °F or °C
  • Optional 4 to 20mA or 0 to 10V analog output
  • Optional RS232 or RS485 serial port
  • Available with up to 4 relay outputs
  • Available with low or high voltage power supply
  • Data logging capability
  • Security PIN protected
  • IP65 rated dust & splash proof face
  • CE approved & 5-year guarantee

The Define Instruments PRO-RTD panel meter accepts direct sensor input from RTD 385, 392, and CU10 temperature probes. It can average inputs across 2, 3, or 4 temperature channels and use the averaged value for a display source, as a data source for analog output, serial output, setpoint control, or the peak and valley values. The PRO-RTD features an option to log and store your data in the controller's internal memory, where it can be printed or accessed with Excel-compatible programs for easy analysis.

The PRO-RTD uses input signal averaging to reduce noise and ensure stable measurements. If the change in input exceeds the averaging window value it will not average, ensuring fast response when there are large differences between readings. If your input signal contains large noise spikes you can increase the size of the averaging window to ensure that these are still averaged as well. Your settings remain secure with PIN protection; the input calibration and setpoint functions have independent codes so you can give access to one and not the other.

Part Number Price Available
PRO-RTD-HV
Show Configuration
Base Price
$412.00
Power Supply
85 to 265VAC / 95 to 370VDC
Relay Outputs
None
Analog Output
None
Serial Port
None
Data Logging
None
Reconfigure
$412.00 2
PRO-RTD-LV
Show Configuration
Base Price
$412.00
Power Supply
15 to 48VAC / 10 to 72VDC
Relay Outputs
None
Analog Output
None
Serial Port
None
Data Logging
None
Reconfigure
$412.00 2

Interested in Other Part Numbers?

Other part numbers are available to order but are not currently in stock. Current availability for non-stock parts is "Usually ships in 1-2 weeks". Click here to select options
