Amprobe ACD-6 PRO Clamp-on Multimeter

Digital multimeter with current measurement up to 1000 A .

$150.99

View Company Reviews
Part Number
  • ACD-6 PRO
Manufactured
Includes
Availability
  • Usually ships in 1-2 weeks
Product Manual Product Specs

Features

  • Measures AC current up to 1000 A
  • Measures AC/DC voltage up to 600 V
  • Resistance
  • Continuity beeper
  • Relative zero mode
  • Auto power off
  • Data hold
  • Accommodates conductors up to 45mm (1.77")

The Amprobe ACD-6 PRO 1000 A clamp-on multimeter measures AC and DC voltage to 600 V and AC current to 1000 A. The Amprobe ACD-6 multimeter includes features such as resistance measurement, continuity beeper, relative zero mode, auto power off, and data hold.

The Amprobe ACD-6 PRO 1000 A clamp-on multimeter has a 3-3/4 digit, 4000 count, LCD display and the clamp jaws can accommodate conductors up to 45 mm (1.77") in diameter. Amprobe ACD-6 PRO multimeters are simple to operate and an excellent option for high current applications.

The Amprobe ACD-6 PRO digital clamp-on multimeter ships complete with:

  • Test leads (MTL-90B)
  • Carrying case
  • Manual

Amprobe ACD-6 PRO Digital Clamp-on Multimeter Specifications

Feature Range Accuracy
DC Voltage
  400.0 mV 1.0% + 3d
  4.000 V, 40.00 V, 400.0 V 1.7% + 3d
  600 V 2.0% + 4d
NMRR: >50 dB @ 50/60 Hz
CMRR: >120 dB @ Dc, 50/60 Hz, Rs=1kΩ
Input impedance: 10 MΩ, 30 pF nominal (1000 MΩ for 400.0 mV range)
Audible continuity tester
Open circuit voltage: 0.4 VDC typical / 400.0 Ω 1.5% + 6d
Audible threshold:   between 10 Ω and 120 Ω
Resistance
  400.0 Ω 1.5% + 6d
  4.000 kΩ, 40.00 kΩ, 400.0 kΩ 1.0% + 4d
  4.000 MΩ 1.5% + 4d
  40.00 MΩ 2.5% + 4d
Open circuit voltage: 0.4 VDC typical
AC Voltage
  50 Hz-500 Hz / 400.0 mV 4.0% + 5d
  50 Hz-60 Hz / 4.000 V, 40.00 V, 400.0 V 2.0% + 5d
  50 Hz-60 Hz / 4.000 V, 40.00 V, 400.0 V 2.0% + 5d
  60 Hz-500 Hz / 4.000 V, 40.00 V, 400.0 V 2.5% + 5d
  50 Hz-500 Hz / 600.0 V 3.0% + 5d
CMRR: >60 dB @ Dc to 60 Hz, Rs=1kΩ
Input impedance: 10 MΩ, 30 pF nominal
Diode Tester
  Open circuit < 1.6 V DC
  Voltage test current (Typical) 0.4 mA
AC Current (Clamp-on)
50 Hz/60 Hz 400.0 A 1.5% + 5d
  1000.0 A 1.5% + 5d
