Features

  • Generate 3,000 psi (200 bar) in 40 seconds
  • 0.001 psi (10 Pa, 0.1 mbar) resolution
  • Specially designed shut-off valve
  • Durable and minimal maintenance
  • Hand-tight quick connectors
  • Material:
    • Ram/adapters: SST
    • Body: SST/aluminum
    • Seals: Buna-N, F357
  • Built-in gas-liquid isolator
  • High-quality screw press

The Additel ADT920 High Pressure Test Pump is a hand operated pressure pump designed to generate pressure from 95% vacuum to 3,000psi (200bar). With a long lever, it just takes 40 seconds to reach 3,000 psi (200 bar). A high-quality screw press is designed for fine pressure adjustment, with an adjustment resolution up to 10 Pa (0.1 mbar). A specially designed shut-off valve makes the pressure as stable as possible during calibration. A built-in gas-liquid isolator protects the pump from moisture and dirt to reduce the need for maintenance. The residual liquid in the pump introduced from devices under test will be pushed out and collected during pressure release. Two hand-tight quick connectors installed on the pump allow easy connecting and disconnecting to the test pump without the need for PTFE tape or wrenches. The 920 is an ideal comparison test pump for pressure instruments calibration.

The Additel 920 is designed to generate pressure from 95% vacuum to 3,000 psi (200 bar) for the high pressure application requiring accurate pressure testing and calibration. It can be used in calibrating high pressure gauges, transmitters, or other pressure measuring instruments.
